rtseries vibration isolation platform

rtseries vibration isolation platform adopts high stability rubber vibration isolator.rtseries vibration isolation platform can effectively cut off from the ground vibration, especially suitable for the mesa have moving parts, and don't want to external vibrationthe moving parts, products widely used in optics, precision measurement, precision measurement, biology, medicine, microelectronics, semiconductor and other fields.

product data sheet

modelmodel

table size(mm)

platform the overall height (mm

maximum load(kg)

screw hole diameter

the pitch of screw(mm)

support legs (only)

the length of the

the width of the

the thickness of the bedplate

rt- 0906.

900

600

50

800

200

m6

25

4

rt- 0906.

900

600

100

800

400

m6

25

4

rt- 1208.

1200

800

100

800

800

m6

25

4

rt- 1509.

1500

900

100

800

800

m6

25

4

rt- 1510.

1500

1000

100

800

800

m6

25

4

rt- 1511.

1500

1100

100

800

800

m6

25

4

rt- 1810.

1800

1000

200

800

800

m6

25

4

rt- 1812.

1800

1200

200

800

800

m6

25

4

rt- 2010.

2000

1000

200

800

800

m6

25

4

rt- 2012.

2000

1200

200

800

800

m6

25

4

rt- 2015.

2000

1500

200

800

800

m6

25

4

rt- 2412.

2400

1200

200

800

800

m6

25

4

rt- 2415.

2400

1500

300

850

800

m6

25

4

rt- 2518.

2500

1800

300

850

800

m6

25

6

rt- 3012.

3000

1200

300

850

800

m6

25

6

rt- 3013.

3000

1300

300

850

800

m6

25

6

rt- 3015.

3000

1500

300

850

800

m6

25

6

rt- 3512.

3500

1200

300

850

800

m6

25

6

rt- 3513.

3500

1300

300

850

800

m6

25

6

rt- 3515.

3500

1500

300

850

800

m6

25

6

rt- 4015.

4000

1500

300

850

800

m6

25

8

rt- 5015.

5000

1500

300

850

800

m6

25

8

rt- 6015.

6000

1500

400

850

3000

m6

25

8

main performance indicators

load capacity:

the biggest1000kg

natural frequency:

5~7.5hz

the maximum dynamic deflection coefficient:

1.1x10

the largest relative displacement:

0.22nm

surface flatness:

0.10mm/msquared
