rsseries high precision optical platform | ||||||||
rsseries high precision optical platform is mainly used in the occasion of no special requirements for vibration isolation, has the very high cost performance products. | ||||||||
product data sheet | ||||||||
modelmodel | table size(mm) | platform the overall height (mm) | maximum load(kg) | screw hole diameter | the pitch of screw(mm) | support legs (only) | ||
the length of the | the width of the | the thickness of the bedplate | ||||||
rs-0906 | 900 | 600 | 50 | 800 | 200 | m6 | 25 | 4 |
rs-0906 | 900 | 600 | 100 | 800 | 400 | m6 | 25 | 4 |
rs-1208 | 1200 | 800 | 100 | 800 | 800 | m6 | 25 | 4 |
rs-1509 | 1500 | 900 | 100 | 800 | 800 | m6 | 25 | 4 |
rs-1510 | 1500 | 1000 | 100 | 800 | 800 | m6 | 25 | 4 |
rs-1511 | 1500 | 1100 | 100 | 800 | 800 | m6 | 25 | 4 |
rs-1810 | 1800 | 1000 | 200 | 800 | 800 | m6 | 25 | 4 |
rs-1812 | 1800 | 1200 | 200 | 800 | 800 | m6 | 25 | 4 |
rs-2010 | 2000 | 1000 | 200 | 800 | 800 | m6 | 25 | 4 |
rs-2012 | 2000 | 1200 | 200 | 800 | 800 | m6 | 25 | 4 |
rs-2015 | 2000 | 1500 | 200 | 800 | 800 | m6 | 25 | 4 |
rs-2412 | 2400 | 1200 | 200 | 800 | 800 | m6 | 25 | 4 |
rs-2415 | 2400 | 1500 | 300 | 850 | 800 | m6 | 25 | 4 |
rs-2518 | 2500 | 1800 | 300 | 850 | 800 | m6 | 25 | 6 |
rs-3012 | 3000 | 1200 | 300 | 850 | 800 | m6 | 25 | 6 |
rs-3013 | 3000 | 1300 | 300 | 850 | 800 | m6 | 25 | 6 |
rs-3015 | 3000 | 1500 | 300 | 850 | 800 | m6 | 25 | 6 |
rs-3512 | 3500 | 1200 | 300 | 850 | 800 | m6 | 25 | 6 |
rs-3513 | 3500 | 1300 | 300 | 850 | 800 | m6 | 25 | 6 |
rs-3515 | 3500 | 1500 | 300 | 850 | 800 | m6 | 25 | 6 |
rs-4015 | 4000 | 1500 | 300 | 850 | 800 | m6 | 25 | 8 |
rs-5015 | 5000 | 1500 | 300 | 850 | 800 | m6 | 25 | 8 |
rs-6015 | 6000 | 1500 | 400 | 850 | 3000 | m6 | 25 | 8 |
main performance indicators | ||||||||
load capacity: | the biggest1000kg | |||||||
the maximum dynamic deflection coefficient: | 1.1x10-3 | |||||||
the largest relative displacement: | 0.22nm | |||||||
surface flatness: | 0.10mm/m2 | |||||||
the adjusting range is: | plus or minus50mm |
